TR 641 top 2 Digital time switch

Home page » Product » Sensor THEBEN » Time switches » TR 641 top2. Công tắc thời gian KTS, lịch năm/1 giây/1 kênh, hỗ trợ thẻ nhớ.

Description

R 641 top2 digital time switch with 1 channel output is designed in DIN rail mounting style for easy installation of power projects, LED display with full parameter for easy user author
Battery back up for 10 years
800 places to be remembered
Automatically memorize sunrise and sunset times throughout the year
Suitable for applications of smart electricity, stairs, watering garden, street lights, ....
Made in: Germany
Warranty 12 months 641

Operating voltage	110 – 240 V AC
Frequency	50 – 60 Hz
Width	3 modules
Installation type	DIN rail
Type of contact	Changeover contact
Switching output	Phase-independent
Opening width	< 3 mm
Program	Yearly program, Astronomical program
Program functions	ON-OFF, Pulse, Cycle
Number of channels	1
External inputs	1
Number of memory locations	800
Power reserve	8 years
Switching capacity at 250 V AC, cos φ=1	16 A
Switching capacity at 250 V AC, cos φ =0,6	10 A
Incandescent/halogen lamp load 230 V	2600 W
Incandescent/halogen lamp load 120 V	1300 W
Energy saving lamps 230 V	37 x 7 W, 30 x 11 W, 26 x 15 W, 26 x 20 W, 11 x 23 W
Energy saving lamps 120 V	18 x 7 W, 15 x 11 W, 13 x 15 W, 13 x 20 W, 11 x 23 W
LED lamp < 2 W	50 W
LED lamp 2-8 W	180 W
LED lamp > 8 W	200 W
Switching capacity min	ca. 10 mA
Shortest switching times	1 s
Time accuracy at 25 °C	≤ ± 0.5 s/day (quartz)
Time basis	Quartz
Stand-by consumption	~0,6 W
Capacity loss max.	1,1 W
Memory card supplied	-
Type of connection	DuoFix spring terminals
Externe Antenne anschließba	-
Display	LCD
Keyboards	4 touch buttons
Housing and insulation material	High-temperature resistant, self-extinguishing thermoplastic
Type of protection	IP 20
Protection class	II according to EN 60 730-1
Voltage	110-240 V AC
Ambient temperature	-30 °C ... +45 °C
