TR 622 top2 Digital time switch

Home page » Product » Sensor THEBEN » Time switches » TR 622 top2. Công tắc thời gian KTS, tuần/1 giây (ngắn nhất), 2 kênh, thẻ nhớ.

The TR 622 top2 digital two-way digital override switch is designed for easy installation of DIN rail mounted electrical installations, full LED display for easy operation. author
Battery back up for 10 years
84 times for 1 channel (42 times ON / OFF)
Suitable for applications of smart electricity, stairs, watering garden, street lights, ....
Made in: Germany
Warranty 12 months

Operating voltage	230 – 240 V AC
Frequency	50 – 60 Hz
Width	2 modules
Installation type	DIN rail
Type of contact	Two-way changeover contact
Switching output	Phase-independent
Opening width	< 3 mm
Program	Weekly program
Program functions	ON-OFF, Pulse, Cycle
Number of channels	2
External inputs	2
Number of memory locations	84
Power reserve	10 years
Switching capacity at 250 V AC, cos φ=1	16 A
Switching capacity at 250 V AC, cos φ =0,6	10 A
Incandescent/halogen lamp load 230 V	2600 W
Energy saving lamps 230 V	170 W
LED lamp < 2 W	30 W
LED lamp 2-8 W	100 W
LED lamp > 8 W	120 W
Fluorescent lamp load (conventional) not corrected	1000 VA
Fluorescent lamp load (conventional) series-corrected	1000 VA
Fluorescent lamp load (conventional) parallel-corrected	730 VA 80 µF
Switching capacity min	ca. 10 mA
Shortest switching times	1 s
Time accuracy at 25 °C	typical ± 0,25 s/day (quartz)
Time basis	Quartz
Stand-by consumption	~0,8 W
Capacity loss max.	2,6 W
Memory card supplied	-
Test approval	VDE
Type of connection	DuoFix spring terminals
Externe Antenne anschließba	-
Keyboards	4 touch buttons
Housing and insulation material	High-temperature resistant, self-extinguishing thermoplastic
Type of protection	IP 20
Protection class	II according to EN 60 730-1
Voltage	230 V AC
Ambient temperature	-30 °C ... +55 °C
