SUL 191 w. Công tắc thời gian analog, tuần, 1 kênh, pin dự phòng.

SUL 191 w. Công tắc thời gian analog, tuần, 1 kênh, pin dự phòng.

  • 4.623.000 vnd
  • 3.698.000 vnd
  • Germany
  • 12 month
  • The SUL 191 w mechanical time switch is an electronic timer that automatically switches on and off for electrical appliances according to the actual clock, with cycle times and automatic cycle repetition. Minimum installation time is 2 hours, 84 conversion segments, 1 output channel, 200 hours battery (rechargeable). Clock display time



  • SUL 191 in mechanical time switch with weekly install program, 1 outlet, easy installation on DIN rail, cabinet or wall (with accessories). Fast connectors with spring-type connectors (no screwdriving required), 2-wire each. The device is standard in size 3 modules.
    SUL 191 w is used in automatic lighting control, billboards, water pumps, watering plants, fountains, aquariums, ventilators, ...

    Main function:
    1 channel control
    Daily program
    Built-in rechargeable battery (NiMH)
    Quartz Watches
    84 segments.
    Shortest switching time: 2 hours
    Clock face shows time and direction 12 / 24h.
    Time can be adjusted backwards or clockwise.
    Spring-loaded spring couplings: single or multi-threaded, with or without thread, 0.5 ~ 2.5mm2, press to release.
    Pre-select closed or open status.
    3 operating modes: Continuous ON / AUTO / continuous OFF
    Display active status (closed / closed).
    A transparent cover protects the device.

    191w1

Supply voltage 220 VAC / 50Hz

Weekly program

Shortest conversion time 2 hours

84 segment conversion

Number of output 1 (Relay output, NO-Com-NC) with load 16A for load and 4 A for load.

Permanent ON / OFF / AUTO

Battery life: 200 hours / 100 hours with 110 volts

Mounted on rails

Protection class IP 20

Operating Environment: - 20 ° C ... + 55 ° C
