LUNA 129 Star - time - Twilight switch with integrated light sensor

Home page » Product » Sensor THEBEN » Twilight switches » LUNA 129 star-time. Công tắc ánh sáng KTS, 2~200lx, trễ 0~10min, c_trình 24h.

Features of LUNA 129 Star - time :

Twilight switch with integrated light sensor
Time function for freely-programmable night switch-off (daily program)
Adjustable On and Off switching delay
to avoid faulty operation caused by lightning, car headlights etc.
Easy programming philosophy
Preset night switch-off (23.00 OFF/5.00 ON), lux values and switch delay
Automatic summer/winter time correction
Cable feed from the back and from below
Cover with snap-on function when opening for the straightforward installation of the device
Captive screws

Operating voltage	220 – 230 V AC
Frequency	50 – 60 Hz
Number of channels	1
Stand-by consumption	~0.6 W
Program	Daily program
Setting range brightness	2 – 200 lx
Preset brightness value	15 lx
Switch-on delay	0 – 10 min
Switch-off delay	0 – 10 min
Type of contact	NO contact
Switching output	Not potential-free (230 V)
Installation type	Wall installation or mast bracket
Type of connection	Screw terminals
Display	LCD-Display
Keyboards	3 touch buttons, 1 test button
Shortest switching times	1 min
Power reserve	1.5 years at 20 °C
Switching capacity	16 A at 230 V AC, cos φ = 1, 10 AX at 230 V AC, cos φ = 0.3
Incandescent/halogen lamp load	2300 W
Halogen lamp load	2300 W
Fluorescent lamp load (conventional) not corrected	2300 VA
Fluorescent lamp load (conventional) series-corrected	2300 VA
Fluorescent lamp load (conventional) lead-lag circuit	2300 VA
Fluorescent lamp load (conventional) parallel-corrected	400 VA 42 µF
Energy saving lamps	90 W
Fluorescent lamp load (electronic ballast)	350 W
LED lamp < 2 W	20 W
LED lamp 2-8 W	55 W
LED lamp > 8 W	70 W
Test approval	VDE
Housing and insulation material	High-temperature resistant, self-extinguishing thermoplastic
Ambient temperature	-35°C ... 55°C
Type of protection	IP 55
Protection class	II
